Shandong Chenma Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of 10000l cream storage tank in China. With abundant experience, we are committed to providing high quality dairy and beverage processing equipment with competitive price. Welcome to buy premium 10000l cream storage tank from our factory.
Standard Specifications:
- Capacity: 500L-100,000L (Customizable)
- Tank Type: Vertical or Horizontal Storage Tank
- Material: Food-grade SUS304 stainless steel (SUS316L optional)
- Tank Structure: Double-wall insulated construction
- Insulation: 80–150 mm high-density polyurethane foam
- Cooling Jacket: Dimple plate cooling jacket
- Cooling System: Chilled water or glycol cooling
- Storage Temperature: 2–8°C (Adjustable according to product requirements)
- Agitator: Low-speed sanitary agitator for gentle and uniform mixing
- Motor: Energy-efficient geared motor with optional VFD speed control
- Temperature Sensor: PT100 high-precision temperature sensor
- Temperature Control: Digital automatic controller or PLC touchscreen system
- Cleaning System: Rotary CIP spray ball
- Manhole: Top sanitary manhole with inspection cover
- Air Vent: Sanitary air vent with sterile filter
- Outlet: Bottom sanitary butterfly valve
- Surface Finish: Interior 2B polish or mirror polished (Ra ≤ 0.4 μm); exterior satin polished
- Support Structure: Stainless steel legs or skirt support
- Power Supply: 220V / 380V / 415V / 440V / 480V, 50/60Hz (Customizable)
Key Features
- Hygienic food-grade stainless steel construction
- Designed for safe storage of whey, cream, and other dairy liquids
- Excellent thermal insulation minimizes temperature fluctuations
- Cooling system maintains optimal storage conditions
- Gentle agitation prevents cream separation and ensures product consistency
- Automatic temperature monitoring and precise control
- Easy-to-clean sanitary design with integrated CIP system
- Corrosion-resistant construction for long service life
- Customizable capacity, dimensions, and control system
Applications
- Cheese production plants
- Dairy processing factories
- Cream production and storage
- Whey collection and storage
- Butter manufacturing
- Ice cream production
- Milk processing lines
- Beverage and liquid food processing plants
Optional Configurations
- PLC touchscreen automatic control
- Chiller system
- Variable Frequency Drive (VFD) agitator
- Load cells for weighing
- Liquid level sensor
- Stainless steel ladder, platform, and safety guardrail
- SS316L stainless steel construction
- Customized inlet, outlet, and piping connections
Advantages
- Preserves the quality and freshness of whey and cream
- Prevents fat separation through gentle agitation
- Reduces energy consumption with high-performance insulation
- Easy to operate, clean, and maintain
- Compatible with automated dairy processing systems
Manufactured in compliance with international food-grade hygiene standards (CE, ISO9001, optional FDA-compliant materials)
The Whey & Cream Storage Tanks are ideal for dairy manufacturers seeking reliable, hygienic, and energy-efficient storage solutions for whey, cream, and other dairy products, ensuring consistent product quality and efficient production workflows.
