Shandong Chenma Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of 500l milk mixing tank in China. With abundant experience, we are committed to providing high quality dairy and beverage processing equipment with competitive price. Welcome to buy premium 500l milk mixing tank from our factory.
Stainless Steel Milk Mixing Tank – Technical Specifications
|
Capacity |
500L |
|
Tank Type |
Vertical |
|
Material |
Food-grade SUS304 stainless steel (SUS316L optional) |
|
Tank Structure |
Single-wall / Jacketed / Insulated (Optional) |
|
Jacket Type |
Dimple plate, Coil, or Conventional jacket (Optional) |
|
Heating Method |
Electric heating, Steam heating, or Hot water heating (Optional) |
|
Cooling Method |
Chilled water or Glycol cooling (Optional) |
|
Insulation |
80 mm Polyurethane Foam (for insulated models) |
|
Mixing Type |
Paddle, Anchor, Propeller, High-speed Disperser (Optional) |
|
Agitator Speed |
20–1,500 rpm (According to mixer type) |
|
Motor Brand |
ABB, Siemens, SEW, Nord, or Chinese premium brands |
|
Motor Power |
0.55–22 kW (Depending on tank size and application) |
|
Temperature Control |
Digital automatic temperature controller |
|
Temperature Sensor |
PT100 temperature sensor |
|
Working Temperature |
0–100°C (Higher temperatures available upon request) |
|
Working Pressure |
Atmospheric or pressurized (Customizable) |
|
Surface Finish |
Internal 2B or mirror polished |
|
Cleaning System |
CIP spray ball (Fixed or rotary) |
|
Manhole |
Top sanitary oval or round manhole |
|
Outlet |
Bottom sanitary butterfly valve or ball valve |
|
Leg Type |
Adjustable stainless steel legs |
|
Power Supply |
220V / 380V / 415V / 440V / 480V, 50/60Hz (Customizable) |
|
Control Cabinet |
PLC or digital control system (Optional) |
Optional Configurations
- Load cells for weighing and batching
- Level sensor
- Bottom high-shear homogenizer
Applications
- Fresh milk mixing
- Milk standardization
- Yogurt production
- Cheese processing
- Cream blending
- Flavored milk preparation
- Dairy ingredient mixing
- Beverage and liquid food processing
- Pharmaceutical and cosmetic liquid mixing
