Shandong Chenma Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of 50tons raw milk silo in China. With abundant experience, we are committed to providing high quality dairy and beverage processing equipment with competitive price. Welcome to buy premium 50tons raw milk silo from our factory.
Specification list for 50tons raw milk silo:
1.Sanitary Stainless steel,inside for the tank will be 2B polish, inner body with stainless steel 316L and outside with stainless steel 304;
2.Inner body diameter is 3000mm, thickness is 5mm-3mm, material is stainless steel 316L;
3.Cylinder height:7500mm;
4.Upper head: diameter:3000mm, thickness 3mm, material: stainless steel316L, conical head, taper angle is 150°; Lower head: diameter: 3000mm,thickness 5mm, material:stainless steel 316L, 5° slope;
5.Outer cladding: Diameter 3200mm, material: stainless steel 304; thickness is 2mm, Bottom outer cladding:flat bottom, thickness is 3mm, material:stainless steel304;
6.Top head: Diameter 3200mm, thickness: 3mm, material: stainless steel 304, conical top, taper angle is 150°;
7.Material of parts in contact with the product: SS316L
8.Surface brushed, welding line polish sanding light belt;
9.Effective capacity:50,000L, total capacity: 53,506L;
10.Diameter is 3200mm, height is 9063mm;
11.Conical top and flat bottom;
12.Equipped with an overflow breathing system DN273mm, material: stainless steel 304;
13.1.5"sterile sample valve, material is stainless steel 316L ;
14.4" milk outlet assembly;
15.3" milk inlet, with thread connection;
16.Side agitator system: stirring power is 7.5KW , 900 rpm, variable frequency, material is stainless steel 316L, aigtator motor brand is SEW;
17.PU insulation, thickness: 100mm;
18.With vortex breaker;
19.Fully welded cladding;
20.Welding method: TIG welding;
21.There are 2pcs CIP spray ball, brand:LYSF;
22.Bimetallic thermometer;
23.With ladder and guardrail for the tank, material: stainless steel 304;
24.With cooling jacket, cooling are is 23m2, thickness of cooling jacket is 1.5mm,volume is 115L, material is stainless steel 304;
25.The tank with alcove;
26.The tank without legs and tank will be mounted on the floor;
27.Complete with associated valves and fittings;
Key Features
- Large-capacity storage for continuous dairy production
- Hygienic food-grade stainless steel construction
- Excellent insulation minimizes temperature loss
- Optional cooling jacket maintains milk at the ideal storage temperature
- Side gentle agitation prevents cream separation without damaging milk quality
- Automatic temperature monitoring and control
- Integrated CIP system for fast and effective cleaning
- Durable, corrosion-resistant design with long service life
- Customizable dimensions and configurations to match plant layouts
Applications
- Dairy processing plants
- Milk collection and cooling centers
- Dairy farms
- Pasteurization production lines
- Cheese and yogurt factories
- Milk receiving and buffer storage
- Beverage and liquid food processing facilities
Optional Configurations
- PLC touchscreen automatic control
- Refrigeration unit
- Load cells for weighing
- Level gauge or radar level sensor
- Ladder, platform, and safety guardrail
- Customized outlet size and piping connections
- SS316L construction for special processing requirements
Advantages
- Designed for hygienic long-term storage of raw milk
- Maintains stable low temperatures to preserve milk quality
- Low operating and maintenance costs
- Suitable for integration into fully automated dairy processing lines
Manufactured according to international food-grade standards (CE, ISO9001, optional FDA-compliant materials)
The 50 Tons Raw Milk Silo is an ideal solution for medium- and large-scale dairy processing operations, providing reliable, energy-efficient, and sanitary milk storage before pasteurization, homogenization, or packaging.
